PATROL 760
A powerful, long-range cruiser able to cope with the most challenging conditions. Long range tanks and a modular design allow the 760 to be built for performance, family boating or a number of commercial uses. The Patrol is built from 4 mm 5083 aluminum plates with 6 and 10mm stringers. With their super deep V, wide chines, and large diameter tubes, the Patrol series offers high maneuverability, high safety, and a soft dry ride even in the roughest conditions. They’re designed to carry large loads and plane quickly and easily with modest horsepower. For charter boat and commercial opera- tors, the modular set-up option means that we can build a layout that suits your requirements. When safety, toughness, and reliability really matter, the Patrol range should be at the top of your list of boats to consider.
STANDARD FEATURES
ORCA® Hypalon tube fabric – Flush mount non-return valves – High tensile chromated & powder coated aluminum hull – Integrated transom supports – Self-draining deck – Integrated under-deck fuel tank – Integrated rear seat with cushion – Engine well – Standup console – Bolster seat – Bow locker with seat cushion – Lifting points and towing eyes – Anti-slip deck – Heavy duty rub strake – Full length keel guard – Highfield dry bag – Foot pump, paddles, repair kit – Leaning post
SPECIFICATIONS
-
Overall Length
25’
-
Internal Length
19’4”
-
Overall Width
9’ 6”
-
Internal Width
5’ 7”
-
Dead Rise
26 degrees
-
Tube Diameter
23”
-
Number of air chambers
6
-
Maximum Load
3153 lbs
-
Maximum People
16
-
Boat Only Weight
2161 lbs
-
Recommended Power
250 hp
-
Maximum Power
300 hp
-
Engine Shaft
Extra Long
-
Fuel Tank
75 gal
-
Design Category
C
FEATURES
The Patrol 760 has more features and options than other RIBs in its Class.
